Tratador de Agua GRÜNBECK GENO-VARIO mini

En Español

Sistema de tratamiento de agua de calefacción GENO ® -VARIO mini es un sistema móvil compacto para el tratamiento de circuitos calientes y fríos. Se utiliza para llenar nuevos sistemas y admite desmineralización / subflujo de subflujo y sanitización en sistemas antiguos. Las impurezas, depósitos de incrustaciones y productos de corrosión se acumulan en los circuitos calientes y fríos. Reducen la eficiencia de los intercambiadores de calor. El tratamiento del agua de llenado del sistema con filtración, desmineralización o ablandamiento garantiza una operación eficiente del sistema (directriz VDI 2035). El sistema se puede ejecutar opcionalmente con un sistema de dosificación disponible por separado para agregar fosfatos para establecer el pH al valor requerido.

Para más información Descargar Ficha Técnica

In English

Heating water treatment system GENO®-VARIO mini is a mobile compact system for treating hot and cold circuits. It is used to fill new systems and supports sanitation and sub-flow demineralisation/sub-flow softening in old systems. Impurities, scale deposits and corrosion products accumulate in the hot and cold circuits. They reduce the efficiency of heat exchangers. The treatment of system fill water with filtration, demineralisation or softening ensures efficient system operation (VDI guideline 2035). The system can be optionally run with a separately available dosing system for adding phosphates to set the pH to the required value.

For more information Download Technical Sheet

Compartir contenido:

Descripción

Tratador de Agua GRÜNBECK GENO-VARIO mini / GENO®-VARIO mini – mobile heating water treatment system

En Español

El sistema móvil compacto listo para conectar GENO ® -VARIO mini está preparado para la instalación del dispositivo de medición de conductividad eléctrica GENO® -Multi-LF.

Volumen de suministro

Ciclo del agua con

  • Bomba de circulación
  • Válvula de retención
  • Deaerator
  • Filtros finos
  • Manómetro y válvula de drenaje / muestreo
  • Medidor de agua
  • Bloque de conexión con derivación y válvula de muestreo
  • 2 válvulas de llenado y drenaje
  • Monitoreo de temperatura
  • Toma de corriente integrada

Maquillaje de agua cruda con

  • Separador de sistema
  • Reductor de presión y manómetro
  • Bastidor de sistema de perfil de aluminio anodizado
  • Preparación del ensamblaje para GENO ®opcional -Multi -LF con sensor de conductividad y válvula solenoide
  • 2 mangueras flexibles para la conexión al sistema de calefacción
  • 2 mangueras flexibles para la conexión del tanque intercambiador

In English

Heating water treatment system GENO®-VARIO mini is a mobile compact system for treating hot and cold circuits. It is used to fill new systems and supports sanitation and sub-flow demineralisation/sub-flow softening in old systems. Impurities, scale deposits and corrosion products accumulate in the hot and cold circuits. They reduce the efficiency of heat exchangers. The treatment of system fill water with filtration, demineralisation or softening ensures efficient system operation (VDI guideline 2035). The system can be optionally run with a separately available dosing system for adding phosphates to set the pH to the required value. The ready-to-connect, compact mobile system GENO®-VARIO mini is prepared for installation of the electrical conductivity measurement device GENO®-Multi-LF.

Scope of supply

Water cycle with

  • Circulation pump
  • Non-return valve
  • Deaerator
  • Fine filters
  • Pressure gauge and draining/sampling valve
  • Water meter
  • Connection block with bypass and sampling valve
  • 2 fill and drain valves
  • Temperature monitoring
  • Integrated power socket

Raw water make-up with

  • System separator
  • Pressure reducer and pressure gauge
  • System rack made of anodised aluminium profile
  • Assembly preparation for optional GENO®-Multi-LF with conductivity sensor and solenoid valve
  • 2 flexible hoses for connection to heating system
  • 2 flexible hoses for connection of exchanger tank
